SMT Line 3

SMT Line 3

1. JUKI KD-775 Dispenser
2. SONY SI-E1000 MK III Chip Mounter
3. SONY SI-F130WK Chip Mounter
4. JUKI KE-760 Chip Mounter

5. ETC NE06-102M40 Nitrogen Lead-free Reflow Oven


SMT Line 3: Production Line and Equipment


This line consists of a tin printing machine,
three chip mounters, and a reflow oven.




JUKI KD-775 Dispenser




SONY SI-E1000III Chip Mounter
Part size: 0201~12mm
Speed: 0.22 sec/point
               18000 points/hr




SONY SI-F130WK Chip Mounter
Part size: 01005~12mm
Speed: 0.139 sec/point
             25890 points/hr
