SMT Line 2

 1. Visual Automatic Tin Printing Machine
 2. SONY SI-E1000MK II Chip Mounter
 3. SONY SI-E1000MK III Chip Mounter
 4. SONY SI-E2000 Chip mounter
 5. ETC  AIS-20-82C Non-lead Reflow Oven

SMT Line 2: Production Line and Equipment

This line consists of a tin printing machine,
three chip mounters, and a reflow oven.



SONY SI-E1000 IIIPlacing Machine
Part size: 0201~12mm
Speed: 0.22 sec/point, 18000 points/hr


Sony SVP2000 Visual Automatic Tin Printing Machine
Printing accuracy: 0.01 mm


SONY SI-E2000 Multifunctional Machine
Part size: 0201~60mm




ETC  AIS-20-82C Non-lead Reflow Oven

8 sections - 16 up and down temperature control areas.
